Diâmetro 31.8mm elemento cerâmico piezo de lado duplo verde com diafragma de 48mm

Elemento de cerâmica piezo FT-4800
  • Part No.: FT-4800

    Resonance Frequency (kHz) : 3.2±0.5

    Resonance Impedance(Ω)≤500

    Capacitance(pF) 30000±30%

    Dielectric Loss ≤5%

    Input Voltage (Vp-p) ≤30

    Operating Temperature(℃) -20~+70

    Storage Temperature(℃) -30~+80

    Metal Material Brass

    Metal Plate Diameter(mm) D=φ31.8±0.2

    Ceramic Disc Diameter(mm d=φ30±0.5

    Metal Plate Thickness(mm) t=0.1±0.02

    Total Thickness(mm) T=0.6±0.05

Description:

Diâmetro 31.8mm elemento cerâmico piezo de lado duplo verde com diafragma de 48mm

Fr(KHz):

3.2±0.5

Cp(±30%nf):

140

D:

Ø30.0

T:

0.1

FT-4800
  • FT-4800
  • What glue is used to bond piezo buzzer element? The glue applied to the piezo diaphragm on the security alarm is generally UV glue, but the glue combined with epoxy + acrylic acid comes out, which can replace UV glue with high toughness and can withstand 260 ℃ high temperature for 10 seconds and 120 ℃ for 90 min It is a kind of epoxy adhesive with high heat resistance, moderate curing strength, high impact resistance, and high humming resistance; It has toughness, impact resistance, displacement resistance and ultra-low linear expansion coefficient, excellent temperature resistance and simple operation.
