There are also some differences in specific applications. For example, electromagnetic buzzers are like washing machines, while piezoelectric buzzers are used for doorbells and electronic clocks. However, there are still many products that use buzzers in our daily life, which can be seen almost everywhere (buzzer products are the ones that give prompts or alarm sounds), such as telephones, walkie talkies, buttons on induction cookers, and the sounds made at the beginning and end of the operation of washing machines; For example, if you see an alarm on the wall of a company or a bank, and it sounds loud and harsh, it is the buzzer used for the alarm. The buzzer is like a horn. Without it, the horn will not sound. In fact, the buzzer is also a component of the horn. Buzzer automobile field: door open prompt tone, seat belt unfastened prompt tone, reversing prompt tone, GPS key tone, entertainment audio; Home appliance applications: refrigerator, washing machine, coffee machine, microwave oven, etc; Digital product application: digital camera, notebook computer, recording pen prompt tone; Instrument application: LCR tester, multimeter prompt tone;

Find high quality audio signaling devices with FBelec’s selection of mechanical buzzers .

Mechanical design buzzer belongs to a special subclass of electromagnetic buzzer, which is composed of oscillator, electromagnetic coil, magnet and shell. Different from the traditional electromagnetic control buzzer, the vibration plate of mechanical design buzzer is embedded in the shell, and its frequency analysis is generally low, about 0.5 kHz. The frequency range of ordinary building electromagnetic buzzer is about 2 kHz. After the power supply (as small as 1.2VDC/1.5VDC/3.0VDC, as large as 110VAC, 220VAC) is connected, the sound is generated by regularly knocking the vibration film on the shell under the interaction of the solenoid coil and the magnet. Mechanical buzzer is mainly used for warning and sounding of electrical products (such as egg furnace zl-ydy2317-005220w, soybean milk machine, etc.). Not only because the frequency emission is 0.5K HZ, the entire vibrating buzzer can be transmitted to the ground through the mouse as a driving mouse, but also as the main part of driving the mouse. Today's mechanical buzzers are usually very active. Connected to the DC power supply, the audio buzzer active mechanical oscillation circuit can send a clear sense of "da, da, DA -," sound and vibration.

FBelec is committed to the development and production of piezoelectric buzzer, electromagnetic buzzer, SMD chip buzzer. It is a professional active buzzer and passive buzzer manufacturer whose products are widely used in: air conditioners, telephones, pagers, copiers, alarm reports, instruments and meters, UPS power supply, motorcycle steering gear, electronic toys, computer terminals, electronic meters, etc.

1. Size: The size of the buzzer will affect the volume and frequency. The minimum size of the electromagnetic buzzer ranges from 7 mm to 25 mm, and the maximum size of the piezoelectric buzzer ranges from 12 mm to 50 mm or more.

2. Working voltage: electromagnetic buzzer, from 1.5 to 24V, and piezoelectric buzzer, from 3V to 220V are both feasible, but generally piezoelectric buzzer is recommended to have a voltage of more than 9V to obtain a loud sound.

3. Current consumption: depending on the voltage, the electromagnetic type can be from tens to hundreds of milliamperes. The piezoelectric type can save more power. A few milliamperes can operate normally, and when the buzzer starts, it needs to consume about three times of current instantly.

4. Drive mode: both types of buzzers have self excitation type. They can emit sound as long as DC is connected. Because the built-in drive circuit is in the buzzer, because of different action principles, the electromagnetic buzzer needs to be driven by 1/2 square wave, and the piezoelectric buzzer needs square wave to have better sound output.

5. Sound pressure: The buzzer usually uses a distance of 10cm as the test standard. If the distance is doubled, it will attenuate by 6dB. If the distance is doubled, it will increase by 6dB. The electromagnetic buzzer can reach the level of 85dB/10cm. The piezoelectric buzzer can be made very loud. Most common alarms are made of piezoelectric buzzers.

6. Connection mode: generally, there are pin (DIP), wire (wire), SMD (SMD), and the way of locking screws for piezoelectric large ones.

There are also some differences in specific applications. For example, electromagnetic buzzers are like washing machines, while piezoelectric buzzers are used for doorbells and electronic clocks. However, there are still many products that use buzzers in our daily life, which can be seen almost everywhere (buzzer products are the ones that give prompts or alarm sounds), such as telephones, walkie talkies, buttons on induction cookers, and the sounds made at the beginning and end of the operation of washing machines; For example, if you see an alarm on the wall of a company or a bank, and it sounds loud and harsh, it is the buzzer used for the alarm. The buzzer is like a horn. Without it, the horn will not sound. In fact, the buzzer is also a component of the horn. Buzzer automobile field: door open prompt tone, seat belt unfastened prompt tone, reversing prompt tone, GPS key tone, entertainment audio; Home appliance applications: refrigerator, washing machine, coffee machine, microwave oven, etc; Digital product application: digital camera, notebook computer, recording pen prompt tone; Instrument application: LCR tester, multimeter prompt tone;

Find high quality audio signaling devices with FBelec’s selection of mechanical buzzers .

Mechanical design buzzer belongs to a special subclass of electromagnetic buzzer, which is composed of oscillator, electromagnetic coil, magnet and shell. Different from the traditional electromagnetic control buzzer, the vibration plate of mechanical design buzzer is embedded in the shell, and its frequency analysis is generally low, about 0.5 kHz. The frequency range of ordinary building electromagnetic buzzer is about 2 kHz. After the power supply (as small as 1.2VDC/1.5VDC/3.0VDC, as large as 110VAC, 220VAC) is connected, the sound is generated by regularly knocking the vibration film on the shell under the interaction of the solenoid coil and the magnet. Mechanical buzzer is mainly used for warning and sounding of electrical products (such as egg furnace zl-ydy2317-005220w, soybean milk machine, etc.). Not only because the frequency emission is 0.5K HZ, the entire vibrating buzzer can be transmitted to the ground through the mouse as a driving mouse, but also as the main part of driving the mouse. Today's mechanical buzzers are usually very active. Connected to the DC power supply, the audio buzzer active mechanical oscillation circuit can send a clear sense of "da, da, DA -," sound and vibration.

FBelec is committed to the development and production of piezoelectric buzzer, electromagnetic buzzer, SMD chip buzzer. It is a professional active buzzer and passive buzzer manufacturer whose products are widely used in: air conditioners, telephones, pagers, copiers, alarm reports, instruments and meters, UPS power supply, motorcycle steering gear, electronic toys, computer terminals, electronic meters, etc.
