Pin Header Connector

Picture	Manufacturer No.	Rated Voltage	Contact Resistance	Contact Material	Rated Current	Application	Operating Frequency	Pin Number	Description	Datasheet	Order
	FBPHC-01	100V	20mΩ	Copper alloy	5A	PCB	Low Frequency	2-20P	5.08 pitch pin header straight plug single row single plastic H=2.5 connector factory direct supply		Send Order
	FBPHC-02	100V	20mΩ	Copper alloy	5A	PCB	Low Frequency	2-20P	3.96 pitch needle single row curved needle flat curved H=3.2 connector		Send Order
	FBPHC-03	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header, double-row vertical paste SMT 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-04	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, three-row single-plastic in-line 2~40P plastic high 1.5 connector		Send Order
	FBPHC-05	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.54 pitch pin header single row double plastic straight plug 1~40P plastic high 1.5/2.0/2.5 connector		Send Order
	FBPHC-06	100V	20mΩ	Copper alloy	5A	PCB	/	2-20P	3.96 pitch pin header, single row vertical paste, glue height 3.2 connector		Send Order
	FBPHC-07	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.0 pitch pin header single row horizontal sticker SMT 1~40P glue height 2.0 board-to-board connector		Send Order
	FBPHC-08	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header double row vertical SMT patch 2~40P glue height 1.5/2.0 connector		Send Order
	FBPHC-09	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header single row in-line 1~40P plastic high 1.5/2.0 connector		Send Order
	FBPHC-10	100V	30mΩ	Copper alloy	1.5A	PCB	/	2-50P	1.27 pitch pin header double row double plastic SMT with inner column 2~50P plastic high 2.5 connector		Send Order
	FBPHC-11	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27*2.54 pitch pin header, straight plug 2~50P glue height 2.5 connector		Send Order
	FBPHC-12	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.54 pitch single row needle straight plug 1~40PIN empty even number PIN connector factory direct supply		Send Order
	FBPHC-13	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	1.0 pitch double row patch pin header plastic height 1.0 2-50p double row single plastic connector		Send Order
	FBPHC-14	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header double row double plastic straight plug 2~40P glue high 1.5/2.0/2.5 connector factory direct supply		Send Order
	FBPHC-15	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header/single row 90 degree curved pin/2~50P/glue height 2.0 connector		Send Order
	FBPHC-16	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch double row pin header plastic height 7.4mm 2~40P plastic height 7.4 connector		Send Order
	FBPHC-17	100V	20mΩ	Copper alloy	5A	PCB	/	2-20P	3.96 pitch elbow pin header glue height 3.2 board-to-board connector		Send Order
	FBPHC-18	100V	20mΩ	Copper alloy	1A	PCB	/	2-50P	1.27 pitch pin header, double row, double plastic vertical sticker SMT 2~50P glue height 1.0/1.5/2.0/2.5 gold-plated		Send Order
	FBPHC-19	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	0.8 pitch pin header double row single plastic SMT H=1.38 gold-plated connector		Send Order
	FBPHC-20	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.54 pitch, 90-degree curved needle, empty PIN, plastic height 1.5/2.0/2.0/2.5 connector		Send Order
	FBPHC-21	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header, double row in-line, plastic height 1.5/2.0/2.5 2~40P connector		Send Order
	FBPHC-22	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header single row double plastic straight plug empty PIN connector		Send Order
	FBPHC-23	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2P	2.54 pitch shorting cap H=6.0 connector		Send Order
	FBPHC-24	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch double row pin 180 degree SMT 2~40P glue height 1.5/2.0/2.5 connector		Send Order
	FBPHC-25	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row, double plastic, straight plug, plastic height 1.5/2.0 2~40P connector		Send Order
	FBPHC-26	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header double row 90 degree bent pin 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-27	100V	20mΩ	Copper alloy	5A	PCB	/	2-20P	5.08 pitch straight pin header single row double plastic H=2.5 2-20p connector		Send Order
	FBPHC-28	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	3P	2.54 pitch U-shaped pin header 3P plastic height 2.5 connector		Send Order
	FBPHC-29	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header double row in-line single plastic 2~40P plastic high 1.5/ 2.0/2.5 gold-plated connector		Send Order
	FBPHC-30	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.54 pitch pin header single row 90 degree curved pin 1~40P plastic height 1.5/2.0/2.5 connector		Send Order
	FBPHC-31	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch, three-row pin header, single plastic 90 degree elbow leg, plastic height 2.5 connector		Send Order
	FBPHC-32	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header single row in-line 2~40P plastic height 1.5/2.0/2.5 board-to-board connector		Send Order
	FBPHC-33	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header 2-40P single row single plastic vertical stick SMT connector		Send Order
	FBPHC-34	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	1-40P	2.54 pitch pin header single row horizontal sticker 1~40P glue height 2.5 connector		Send Order
	FBPHC-35	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row double plastic straight plug, glue height 1.5/2.0 2~40P board to board connector		Send Order
	FBPHC-36	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row 90 degree bent pin 2~40P glue height 4.0 connector factory direct supply		Send Order
	FBPHC-37	100V	20mΩ	Copper alloy	5A	PCB	Low Frequency	2-20P	3.96 pitch single row pin header double plastic plastic height 3.2 connector		Send Order
	FBPHC-38	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27*2.54 pitch double plastic pin header vertical stick SMT 2~50P glue height 2.5 connector		Send Order
	FBPHC-39	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch double row needle 90 degree curved needle 2~40PIN glue height 7.4 connector		Send Order
	FBPHC-40	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch pin header 180 degree SMT 2~40P glue height 1.5 /2.0/2.5 connector		Send Order
	FBPHC-41	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row horizontal SMT 2~40P glue height 2.0 connector		Send Order
	FBPHC-42	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row in-line 2~40P plastic high 1.5/2.0 connector		Send Order
	FBPHC-43	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27*2.54 pitch pin header 90 degree curved pin 2~50P plastic height 2.5 connector		Send Order
	FBPHC-44	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row horizontal patch 2~40P glue height 2.0 tinned connector		Send Order
	FBPHC-45	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header, double row 90 degree bent pin 2~40P glue height 2.0mm connector factory direct supply		Send Order
	FBPHC-46	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header, double row horizontal sticker SMT 2~50P glue height 2.5 connector		Send Order
	FBPHC-47	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header double row 90 degree bent pin 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-48	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header, double row double plastic straight plug 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-49	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pin row single row double plastic straight plug 2~50P glue height 1.0/1.5/2.0/2.5 gold-plated connector		Send Order
	FBPHC-50	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch pin header three-row straight plug 2~40P plastic high 2.0 connector		Send Order
	FBPHC-51	100V	20mΩ	Copper alloy	1.5A	PCB	/	2-40P	2.0 pitch pin header/single-row vertical sticker SMT/2~40P glue height 1.5/connector		Send Order
	FBPHC-52	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header, double row in-line 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-53	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch pin header, single row vertical paste SMT 2~50P glue height 1.0/1.5/2.0/2.5 connector		Send Order
	FBPHC-54	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	1.0 pitch pin header double row double plastic SMT patch 2-50P connector		Send Order
	FBPHC-55	100V	20mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female header, single row in-line, plastic height 8.5 height type, PC104 terminal gold-plated 2~40P		Send Order
	FBPHC-56	100V	30mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 mm pitch female double row in-line plastic high 6.35 glued connector		Send Order
	FBPHC-57	100V	30mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch female row, double row in-line, 6.35 high, Y-end, gold-plated 2~40P connector manufacturer		Send Order
	FBPHC-58	100V	30mΩ	Copper alloy	1.5A	PCB	/	2-40P	2.0 pitch female row, double row straight plug, plastic height 4.0 2~40P connector		Send Order
	FBPHC-59	100V	30mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch female row, double row straight plug, plastic height 3.5 terminal gold-plated 2~40P connector factory direct supply		Send Order
	FBPHC-60	100V	30mΩ	Copper alloy	3A	PCB	Low Frequency	2-40P	2.54 pitch female double row 90 degree curved needle glue high 8.5/Y end/gold-plated 2~40P		Send Order
	FBPHC-61	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	1.0 pitch female row single row horizontal stickers SMT 2~50P glue height 2.0 gold-plated connector		Send Order
	FBPHC-62	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row, double row horizontal sticker, glue height 8.5 Y-type terminal 2~40P connector		Send Order
	FBPHC-63	100V	30mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch female header, single-row vertical paste SMT glue height 2.0/3.4/4.3 2~50P board-to-board connector		Send Order
	FBPHC-64	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row single row centipede foot glue height 5.0/2~40P/connector		Send Order
	FBPHC-65	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row single row in-line plastic height 5.7 Y end 2~40P connector		Send Order
	FBPHC-66	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row single row pre-break centipede foot glue high 8.5/2~40P connector manufacturer		Send Order
	FBPHC-67	100V	30mΩ	Copper alloy	7.5A	PCB	/	2-40P	5.08 pitch female row/single row in-line/dual pin/plastic height 8.9 connector		Send Order
	FBPHC-68	100V	30mΩ	Copper alloy	7.5A	PCB	/	2-40P	5.08 pitch female vertical SMD glue height 8.9 2~20P connector		Send Order
	FBPHC-69	100V	30mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch female row, double-row vertical paste SMT glue height 4.3 with large and small columns and side foolproof block 2~50P		Send Order
	FBPHC-70	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female double row in-line glue high 8.5/Y end gold-plated 2~40P connector		Send Order
	FBPHC-71	100V	30mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 pitch female header single row SMT plastic height 4.0/4.3 connector		Send Order
	FBPHC-72	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	0.8*1.2 spacing female header SMT vertical paste 2~50P glue height 3.1 gold-plated connector		Send Order
	FBPHC-73	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch row masterbatch height 8.5 double row in-line with convex & non-convex Y end 2~40P		Send Order
	FBPHC-74	100V	30mΩ	Copper alloy	3A	PCB	/	5-40P	2.54 pitch female row, double row in-line with semi-convex, glue height 8.5 Y end, gold-plated 5~40P		Send Order
	FBPHC-75	100V	30mΩ	Copper alloy	1.5A	PCB	/	2-40P	2.0 pitch double row 90 degree angled female row female Y end/adhesive height 6.35 2~40P connector		Send Order
	FBPHC-76	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row single row straight plug glue height 8.5 U end 2~40P		Send Order
	FBPHC-77	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female header double row vertical paste SMT with/without column glue height 3.5 2~40P connector		Send Order
	FBPHC-78	100V	30mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27 pitch female glue height 2.0/3.4/ double row vertical paste SMT 2~50P connector		Send Order
	FBPHC-79	100V	30mΩ	Copper alloy	0.75A	PCB	Low Frequency	2-50P	1.27 pitch female header, side insertion type SMT glue height 3.5 2~50P connector factory direct supply		Send Order
	FBPHC-80	100V	30mΩ	Copper alloy	1A	PCB	Low Frequency	2-50P	1.27-pitch upper plug-in row masterbatch height 2.0 double row vertical paste 2~50P connector		Send Order
	FBPHC-81	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch double-row in-line plug-in type robust female header, high 6.8/2~40P connector		Send Order
	FBPHC-82	100V	30mΩ	Copper alloy	3A	PCB	/	2-40P	2.54 pitch female row single row straight plug plastic height 3.5 Y-type terminal 2~40P		Send Order
	FBPHC-83	100V	30mΩ	Copper alloy	1.5A	PCB	/	2-40P	2.0 pitch female row single row in-line plastic high 2.0/4.0/4.3/4.6 2~40P		Send Order
	FBPHC-84	100V	30mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0-pitch side-insertion female header, 90-degree elbow, 4.9 high-glue connector, 2~40P connector		Send Order
	FBPHC-85	100V	30mΩ	Copper alloy	1.5A	PCB	Low Frequency	2-40P	2.0 spacing female row, double row straight plug, plastic height 6.35 heightened type Y-end PC104 terminal 2~40PIN		Send Order
	FBPHC-86	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch simple cow, straight plug and glue type, main body glue height 8.8, terminal gold-plated 6~64P connector		Send Order
	FBPHC-87	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch in-line short body glue 6.35 gold-plated 6~64P connector		Send Order
	FBPHC-88	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 Pitch shortened SMT vertical stickers H=6.35 gold-plated 6~64P		Send Order
	FBPHC-89	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-100P	1.27 pitch two-piece SMT vertical sticker heightened type with inner column, glue height 9.9 10~100P		Send Order
	FBPHC-90	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-100P	1.27*2.54 pitch simple horns, straight plug type, glue height 5.6, gold-plated 10~100P		Send Order
	FBPHC-91	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-100P	1.27 pitch simple cow SMT vertical post with post without post, glue height 4.9 10~100P, terminal gold-plated		Send Order
	FBPHC-92	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch smashed type cow glue high 10.0 off-white terminal half gold 6~64P		Send Order
	FBPHC-93	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch simple cow glue high 8.8/SMT patch with/without column gold-plated board-to-board connector		Send Order
	FBPHC-94	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0-pitch, straight-in glue, height 5.7, gold-plated 6~64P connector		Send Order
	FBPHC-95	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch simple cow 90 degree curved needle, 6.35 height glue, with window in the middle, with bayonet on both sides 6~64P		Send Order
	FBPHC-96	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch, straight plug type, plastic height 5.7 lengthened plastic heightened 6~64P		Send Order
	FBPHC-97	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch, straight plug type, high 5.7 gold-plated 10~100P connector		Send Order
	FBPHC-98	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27*2.54 pitch simple horn 90 degree curved needle glue high 5.6/10~100P		Send Order
	FBPHC-99	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch Jianniu 90 degree curved needle glue high 5.7 Pujin 10~100P connector		Send Order
	FBPHC-100	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27*2.54 pitch Jianniu SMT stand glue, high 5.6 terminal gold-plated 10~100P		Send Order
	FBPHC-101	100V	20mΩ	Copper alloy	1.5A	PCB	/	6-64P	2.0 pitch simple cow/SMT vertical sticker/Glue height 5.7/6~64P/connector		Send Order
	FBPHC-102	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch simple cow 90 degree angle angle 4.9 10~100P terminal gold-plated		Send Order
	FBPHC-103	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch simple cow glue high 4.9/SMT vertical sticker with inner column/Pujin/10~100P		Send Order
	FBPHC-104	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch simple cow glue high 4.9 in-line type / terminal gold-plated/10~100P connector		Send Order
	FBPHC-105	100V	20mΩ	Copper alloy	3A	PCB	/	6-64P	2.54 pitch simple cow in-line type, high 8.8 6~64P terminal gold-plated connector		Send Order
	FBPHC-106	100V	20mΩ	Copper alloy	1.5A	PCB	/	6-64P	2.0 pitch simple cow 90 degree curved needle lengthened plastic plastic height 5.7 gold-plated 6~64P		Send Order
	FBPHC-107	100V	20mΩ	Copper alloy	1A	PCB	/	10-100P	1.27 pitch simple cow SMT vertical tape with positioning column, glue height 5.7 10~100P connector		Send Order
	FBPHC-108	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-100P	1.27 pitch two-piece simple cow, straight plug, high type, glue height 9.9 10~100P gold-plated		Send Order
	FBPHC-109	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-100P	1.27 pitch simple cow plus plastic SMT vertical sticker heightened type, main body height 5.7 10~100P connector		Send Order
	FBPHC-110	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch horns SMT patch type 6~64P with long and short ear buckles connector		Send Order
	FBPHC-111	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-60P	1.27 pitch horn 90 degree curved needle with ear buckle 10~60P connector		Send Order
	FBPHC-112	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch piercing crimping horn 6~64P wire-to-board connector with ear buckle		Send Order
	FBPHC-113	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch horn straight plug black/off-white with ear buckle 6-64P wire-to-board connector		Send Order
	FBPHC-114	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch horns in-line type/angled pin/patch type 6~64P connector with ear buckle		Send Order
	FBPHC-115	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch pierced horn with positioning hole and ear buckle 6~64P wire-to-board connector		Send Order
	FBPHC-116	100V	20mΩ	Copper alloy	1.5A	PCB	/	6-64P	2.0 horn/90 degree looper/with long and short ear buckles/6~64P/wire to board connector		Send Order
	FBPHC-117	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-60P	1.27 pitch horns in-line type 10~60P wire-to-board/board-to-board connector with ear buckle		Send Order
	FBPHC-118	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch horns 90 degree curved needle with long/short ear buckle connector		Send Order
	FBPHC-119	100V	20mΩ	Copper alloy	3A	PCB	Low Frequency	6-64P	2.54 pitch horns SMT patch with long and short ear buckles 6~64P connector		Send Order
	FBPHC-120	100V	20mΩ	Copper alloy	1.5A	PCB	Low Frequency	6-64P	2.0 pitch horns 90 degree curved needle with long and short ear buckles 6~64P connector		Send Order
	FBPHC-121	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-60P	1.27 pitch horns SMT patch type 10~60P connector with ear buckle		Send Order
	FBPHC-150	100V	20mΩ	Copper alloy	1A	PCB	Low Frequency	10-60P	2.0 pitch pin head connector straight plug, high type		Send Order

• What is Pin Header

  A pin header (or simply header) is a form of electrical connector. A male pin header consists of one or more rows of metal pins molded into a plastic base, often 2.54 mm (0.1 in) apart, though available in many spacings.Male pin headers are cost-effective due to their simplicity. The female counterparts are sometimes known as female headers (also as pin sockets), though there are numerous naming variations of male and female connectors.




  Pin Header Connectors

  Pin header connectors comprise several different means of connection. Generally, one side is a series of pins which are soldered to a PCB, and they can either be at a right-angle to the PCB surface (usually called "straight") or parallel to the board's surface (confusingly referred to as "right-angle" pins). Such connectors come in a variety of pitches, and may have any number of individual rows of pins.




  Headers are a simple connector that can be used in a wide variety of applications, from industrial to consumer electronics. Pin headers consist of one or multiple rows of metal pins aligned into a molded plastic base. Pin headers come in a vast selection of options related to the number of pins or rows, pitch, height, and mounting orientation. Pin headers offer inexpensive, reliable, robust solutions to effectively connect one PCB to another. Pin headers are known as the male side of this connector solution. Their corresponding counterpart is known as the female header.

•

• According to the standard classification of pin connectors in the electronics industry:



  According to the spacing, it can be roughly divided into five categories: 2.54mm, 2.00mm, 1.27mm, 1.00mm, and 0.8mm. Depending on the number of rows, there are single row needles, double row needles, triple row needles, etc; According to the packaging rules, there are SMT (horizontal/vertical mounting), DIP (direct insertion/bending insertion), etc; Divided by installation method: 180 ° indicated by S, 90 ° indicated by W, SMT indicated by T table



  Industrial Control And Automation

  Pin header used in industrial automation systems connect:

  ● Inputs and outputs to/from PLCs and controllers.

  ● HMIs and their integrated touch panels.

  ● System components like drives, power supplies, safety controls, sensors, etc.

  ● External circuits for power, controls, management, etc.

  Removable connections aid troubleshooting and replacement of components in automation systems.




  Smart Home Devices

  Even in smart home devices and appliances, you will see headers used for:

  ● Connecting integrated touchscreen panels.

  ● Linking components like control boards, sensors, Wi-Fi modules.

  ● Providing serviceability access to internal electronics.

  ● Power and data ingress/egress.

  Header pin usage spans the spectrum from complex industrial equipment down to consumer smart home tech.




• 3 Tips To Consider When Ordering Pin Header For Your Assembly



  1. Identify a Supplier Who Can Achieve Your Desired Custom Pin Design

  Before placing an order, you will need to have your design concept ready. Custom pin header achieve different connection purposes. You can sketch your idea on paper or 2D or 3D CAD for more accurate visualization for final customization.

  The main questions to ask yourself when it comes to designing a custom pin from scratch are:

  Are You Customizing An Entire New Design Or Part Of An Existing Pin Design?

  As mentioned earlier, there are several custom pin designs already. However, when customizing a custom pin, you probably have a unique connection need that the existing contact pin header aren't meeting, either in part or as a whole.

  Define the need for a custom pin and the specifications you'll require for the new prototype. This initial consideration is crucial as it helps you and your supplier to explore the best practical ways and methods you can adopt to create the custom pin in design and cost.



  What Materials Will It Take To Create The Custom Pin?

  The material a contact pin comes in plays a paramount role in its connectivity to other machine parts, service applicability, and final production cost. These materials include those that create the base metal of the pin and any plating you may want on your custom design.

  Consider the different properties of different materials and the various ways in which these materials work together to be more effective and applicable for the part of the machine under development.



  2. Know What Your Assembly Requires in Terms of Production

  Once you have the design ready, the next important consideration is where to get your custom pin header produced. Again, you'll want to share this responsibility with a manufacturer who understands every aspect of your design.

  An experienced manufacturer should be able to produce quality custom pins that are devoid of flaws. Choose a manufacturer with systems in place to create custom pins including vision inspection processes to ensure your custom pin header diameter, length, thickness, and other parameters as you envision in your design.

  Pin header come in varying sizes and shapes, and tolerances in their dimensions guarantee their geometrical tolerances and applicability are accomplished. Choose a company that understands your design concept and can advise and produce a working custom pin that meets the dimensional needs of your connecting parts or machines.

  The method by which your custom pin is produced bears a lot of weight on supply and the final cost of production. Depending on the intricacy of your design, you can opt for either of these production methods:




  Swaging

  The swaging method is best known for producing accurate and efficient custom designs with minimal to zero material losses during manufacturing. This method uses a metal, cold-forming, swaging press and die to progressively form a solid wire or strip of metal into a custom pin design.



  Stamping

  The stamping method involves using a stamping press and progressive die to shape metal into the desired design. Stamping involves more physical actions on the metal than swaging to achieve the desired. These actions or processes include blanking or punching the metal to for shaping and creating flanges where necessary, embossing, blanking, and coining the metal to achieve dimensional accuracy.



  Screw Machining/Turning

  The screw machining/turning method involves feeding metal rods through a turning press producing loose piece interconnect pins and contacts. This process creates a lot of metal scrap which adds cost to this fabrication pin forming option.

  The above methods produce quality custom pin header but at different timelines and cost implications. Analyze the best equipped and economically and environmentally suited to build your custom pin design, and prepare your order based on the ability of the manufacturer to create and deliver in a time and cost-conscious manner.



  3. Ask Your Manufacturer About any Additional Cost Implications

  With a ready design and production processes in mind, the next thing to do is consider the cost implications for producing the custom pins. Manufacturers will quote for you based on the method and materials they use to create your custom pin. A low-cost quote does not necessarily equal quality production, and neither does a high quote.

•


  About FBelec


  FBelec is a leading global connector supplier with approximately 6000 employees, providing high-performance products and services to businesses in over 110 countries worldwide. The company designs, manufactures, and sells products for customers, covering a wide range of industries including automotive, computer, communication equipment, industrial machinery, medical, household appliances, consumer electronics, instruments, and military.



  The company is committed to providing customers with high-quality, innovative products and "one-stop" product solutions. With years of joint efforts and the support of our customers, FBelec has gradually formed its main research and development and production bases in Kunshan, Heyuan, and Dongguan. We have also established business bases in Hong Kong, Taiwan, the United States, Germany, Singapore, Japan, India, Canada, and other places to serve global customers.



• Welcome to the era of customization

  FBelec's accumulation in the field of connectors over the past 20 years has laid the foundation for the era of customization. Expected demand and market development trends, through an ambitious research and development plan, FBelec Committed to developing cutting-edge technologies. Every year, the company invests over 10% of its sales revenue in developing and manufacturing new products. Currently, we have over 200 highly skilled electrical, mechanical, and process engineers working at our two development centers to provide customers with a complete set of connector product solutions. The fields involved include the Internet of Things, the Internet of Vehicles, communication equipment, industrial machinery, healthcare, household appliances, consumer electronics, instruments, and the military goods market.

  ORDER NOW

• • •

    BSCI Certificate

  • •

    CE Certificate

  • •

    FCC Certificate

  • •

    ROHS Certificate

  • •

    UKCA Certificate




  • •

    ISO9001 Certificate

  • •

    BQB Certificate

  • •

    IP56 Report

  • •

    EMC Report

  • •

    Appearance Patent

•


  FBelec Pin connector

  Pin, a kind of connector, English Name: pin header.

  This connector is widely used in PCB circuit boards in electronics, electrical appliances and instruments. Its function is to act as a bridge between blocked or isolated circuits in the circuit and undertake the task of current or signal transmission. It is usually used together with the busbar to form a plate-to-plate connection; or it is used together with the electronic harness terminal to form a board-to line connection. It can also be used for plate-to-plate connection independently.

  Due to different specifications required by different products, there are many types and specifications of pin arrangement, which are classified according to the standard of pin arrangement connector in the electronic industry.

  According to the spacing, it can be roughly divided into five categories: 2.54mm, 2.00mm, 1.27mm, 1.00mm and 0.8mm. According to the number of rows, there are single row needles, double row needles and three row needles. According to the packaging rules, there are SMT (horizontal / vertical), plug-in dip (straight / curved), etc. According to the installation method, 180 ° is represented by s, 90 ° is represented by W, and SMT is represented by T.




  Number of rows: single row, double row, three row, four row, up to four rows.

  Number of stitches: 02to80

  Pin: straight foot, bent foot, SMT; The size of the needle.

  Dimensions: overall dimensions: length, width, thickness and row spacing.

  Spacing: 0.8, 1.0, 1.27, 2.0, 2.54 spacing.

  Material: refers to the contact material and surface treatment, and insulator material.

  Packing: bubble shell, roll bag, bulk.

  Material: pin material: brass or phosphor bronze; Insulator material: plastic UL94V-0.

  Surface treatment: gold plating 0.8u, tin plating and nickel plating.

  Processing technology: the main processing process of row needle is: first process the pin with brass (or phosphor bronze) as required. Nickel plating and then gold plating shall be carried out as required, and then the insulator part shall be processed with the die, and finally the ruler shall be measured on the special equipment. It is required to insert the pin into the insulator.

  Note: there are many factors that affect the price, usually the biggest ones are gold plating, needle length, etc.

  Features: single row and double row, straight needle and curved needle, pin spacing of 2.54mm and 3.96mm, various pin lengths.

  Row needle application

  ● Data processing

  ● Computer

  ● Program control equipment

  ● Electronic measuring equipment

  ● Automatic control

  ● Automation

  ● Communication




  The section of rectangular pin is 0.8 × 1.6mm, load current 7.5A. The jack has at least two independent shrapnel and four contact points. The jack structure can prevent misinsertion. 254 / I series square pin section is 0.64 × 0.64mm。 The above two pins adopt blunt edge angle design, which can be applied to the field of high frequency technology. The contact part of pinhole is plated with gold, with corrosion resistance, low contact resistance and high reliability.




  Pin header / male pin header


  Row pins are generally widely used in the connection of PCB boards, with the reputation of universal connector. Generally, they are paired with connectors such as bus bar, wire end, etc. With the competition in the pin connector market, some manufacturers start with electroplating (imitation gold) and materials (green clad steel, alloy, etc.) to reduce costs, but also reduce the service characteristics and service life of products.Header Connector socket.
