Slide Switch

Picture	Manufacturer No.	Rated Voltage	Rated Current	Description	Datasheet	Order
	SK-14D02	50V	0.3A	1p4t toggle switch sk-14d02 low current four gear paragraph type hand feeling white handle toy switch		Send Order
	SS-22F17	50V	0.3A	High quality two row two gear ss-22f17 sliding switch 2p2t mechanical medical digital toggle switch		Send Order
	SS-14D01	50V	0.3A	Small current toggle switch ss-14d01 four section function toggle professional switch for electrical toys		Send Order
	SS-23H21	50V	0.3A	Toggle switch ss-23h21 toy third gear travel double row perforated PCB sliding switch		Send Order
	SS-23H02	50V	0.3A	The straight handle toggle switch SS-23H02 has three gears and two rows of small current, which makes it feel good		Send Order
	SS-23L13	12V	0.1A	Vertical push switch ss-23l13 toy 3rd gear sliding switch stroke double row perforated high current		Send Order
	SS-25D01	50V	0.3A	push switch ss-25d01 handle high force optional side handle sliding switch		Send Order
	SS-12D10	50V	0.3A	High current two gear toggle vertical ss-12d10 sliding switch 1p2t hair dryer three pin band on		Send Order
	SS-23H25	50V	0.3A	High current toggle switch ss-23h25 toy 3rd gear sliding switch stroke double row eight pin with hole		Send Order
	SS-24N01	50V	0.3A	Micro mini 12 pin horizontal slide switch interruptor on-off mini Slide Switch		Send Order
	SS-23H03	50V	0.3A	Slide Switch sp3t 4pdt 2p4t 2p3t 3pin 6pin 8pin defond mini slide switch 2/3/4 position 2p2t DPDT smd smt spdt slide switch		Send Order
	SK-22H03	50V	0.3A	MINI slide switch 2P2T SMD SMT 4 pin 2 position side slide mini toggle switches		Send Order
	SS-23D03	50V	0.3A	Temperature resistant three gear toggle switch ss-23d03 sliding switch 2p3t manufacturer direct three-stage vertical		Send Order
	SK-44D04	50V	0.3A	Sk-44d04 fourth gear side handle paragraph type hand feeling toy cleanser toggle switch		Send Order
	SS-23L02	50V	0.3A	Vertical toggle ss-23l02 toy 3rd gear sliding switch travel switch without ear double row with hole		Send Order
	SK-24F01	50V	0.3A	Double row four gear sliding switch sk-24f01 high temperature handle paragraph type hand feeling toy switch		Send Order
	SK-42D01	50V	0.3A	MINI Miniature 1P2T 7Pin SMD Slide Switch For DIY Electronic Accessories		Send Order
	SK-43D03	50V	0.3A	Small current three-stage toggle sk-43d03 side handle handle handle toy switch		Send Order
	SK-23D09	50V	0.3A	Side handle push switch third gear high quality low current sliding switch		Send Order
	SK-22F14	50V	0.3A	High quality two gear toggle switch side handle small current earphone toy switch recommended by the manufacturer		Send Order
	SK-22H07	50V	0.3A	Two gear toggle switch small current sk-22h07 side handle high temperature resistant toy earphone switch		Send Order
	SK-22H26	50V	0.3A	Two gang toggle switch manufacturer direct selling side handle small current earphone hair dryer switch		Send Order
	SK-23E01	50V	0.3A	Micro mini 12 pin horizontal slide switch interruptor on-off mini Slide Switch		Send Order
	SK-22J03	50V	0.3A	Micro mini 12 pin horizontal slide switch interruptor on-off mini Slide Switch		Send Order
	SK-63D03	50V	0.3A	MINI slide switch 2P2T SMD SMT 4 pin 2 position side slide mini toggle switches		Send Order
	SK-42H13	50V	0.3A	MINI Miniature 1P2T 7Pin SMD Slide Switch For DIY Electronic Accessories		Send Order
	SK-43D01	50V	0.3A	Black 50mA 12VDC Metal PCB Terminal 4P2T 12 Pin Slide Switch		Send Order
	SK-22D14	50V	0.3A	180 Degree Type Single Row Double Rows Spdt Dpdt Slide Switch SS-Series Pcb Mounted On Off 2 3 4 Position Vertical Slide Switch		Send Order
	SK-13D18	50V	0.3A	Horizontal Gear Shifting Slide Switch Handle height 2 to 8MM 1P2T Switch Slide Switch HookH		Send Order
	SK-24D03	50V	0.3A	ivide the three legs plug-in Vertical small toggle switch Side patch slide switch Horizontal side dial pin fluctuation		Send Order
	SK-14D01	50V	0.3A	Hole pin 3.8 high current 3A SS-12D10G5 switch 2 Position push key toggle switch 3pin slide switch		Send Order
	SK-22F01	50V	0.3A	2p2t slide switch SS22F24 2P2T 6 pins position mini switch knob=5/7 gold platting defend slide switches		Send Order
	SK-12F02	50V	0.3A	7-segment mini toggle switch vertical, small 7-position vertical slide switch, 7-position vertical slide switch 7-position		Send Order
	SK-22F12	50V	0.3A	slide switch smd 12v mini sliding switch vertical slide switches ROHS		Send Order
	SK-12F16	50V	0.3A	50V DC 0.5A 1P2T PCB panel vertical 2 position 3 pin toy slide switch		Send Order
	SK-43D09	50V	0.3A	Industrial Double Row 2P2T 6Pins Through Hole Vertical Type PCB Slide Switch		Send Order
	SK-22F02	50V	0.3A	dpdt mini Miniature power slide switch 2 pole 4 position FBELEC Brand		Send Order
	SK-22F10	50V	0.3A	High Quality Horizontal Slide Switch Miniature Slide Switch Max Body OEM Style Knob slide switch		Send Order
	SK-23H04	12V	0.1A	igh quality Best price 2p3t vertical slide switch 3 three position slide switch		Send Order
	SK-23D05	50V	0.3A	Side handle toggle switch sk-23d05 three gear switch sliding type, good hand feel and temperature resistance		Send Order
	SK-24D07	50V	0.3A	Mini Vertical Slide Switch 1P2T 3 Pin Toggle Switch SMD PCB DPDT Vertical Switch High Quality		Send Order
	SS-63D01	50V	0.3A	The high quality SPDT 1P2T 2 Position 3 Pin PCB Panel Vertical Slide Switch		Send Order
	SS-23D14	50V	0.3A	Factory Hot sale horizontal knob DC 50V 0.5A 2P3T SK series slide switch		Send Order
	SS-43D02	50V	0.3A	3 side pin through hole terminal 1p2t slide switch on-off switch sliver plated		Send Order
	SS-43D03	50V	0.3A	Straight handle toggle switch three gear electric earphone switch handle high temperature resistance		Send Order
	SS-42F01	50V	0.3A	Widely Used High Quality 8A 250VAC 8 Pins Horizontal Slide Switch For Toys		Send Order
	SK-12E12	50V	0.3A	Interruptor on-off mini 1 Way 2 Band Slide Switch PCB Mount		Send Order
	SS-23F10	50V	0.3A	SMD type tact switch ,8 pins 3 position min slide switch		Send Order
	SS-22K26	50V	0.3A	3A high current toggle switch sliding switch 2p2t for medical equipment and electrical appliances		Send Order
	SS-22F48	50V	0.3A	Slide switch 6 / 7 position pin 4 way slide switch waterproof aluminum slide switch for hair dryer		Send Order
	SS-22F04	50V	0.3A	50mA PCB Terminal 6Pin Panel Mount 2P2T mini Slide Switch sliding door contact switches aluminum 3 position slide switchH		Send Order
	SS-22D03	50V	0.3A	MINI slide switch 2P2T DPDT DIP 6 pin side slide mini toggle switches white mini vertical slide switch		Send Order
	SS-12D11	50V	0.3A	KNOB LENGTH 3-15MM 2P3T VERTICAL SLIDING SWITCH		Send Order
	SS-12E07	50V	0.3A	High current two gear toggle switch three pin 1p2t hair dryer earphone toy switch		Send Order
	SS-12E13	50V	0.3A	Test equipment electric mechanical 5M series SPDT industrial slide switch		Send Order
	SS-13D01	50V	0.3A	Stainless steel 6 pins 2position horizontal momentary smd PCB on off Slide switch		Send Order
	SS-13F24	50V	0.3A	Mini slide switch waterproof SMD SMT 4 pin 3 position side mini micro slide switches 2P3T		Send Order
	SS-13F03	50V	0.3A	push key switch SMT 3 position 8 pin slide switch SMD FBELEC manufacturer		Send Order
	SS-12F24	50V	0.3A	small toggle Vertical small toggle switch Side patch slide switch Horizontal side dial pin fluctuation		Send Order
	SS-12F23	50V	0.3A	1P2T with 3 pins Slide Switch Push on toys from factory supply		Send Order
	SS-12D02	50V	0.3A	1P2T PCB panel vertical 2 position 3 pin vertical toy slide switch		Send Order
	SK-24D02	50V	0.3A	6 pin single row slide switch 4 position right angle 2p4t slide switch		Send Order
	SS-22D28	50V	0.3A	Single Row 3 pin 2 way Right Angle Slide Switches 1p2t PCB Mount AC 250V 3A Slide Switch		Send Order
	SK-12F14	50V	0.3A	ON-Off Action 6 Poles DPDT Circuit Actuator Height Solder Lug Terminals Slide Switch		Send Order
	SK-22D02	50V	0.3A	sliding door contact switches aluminum 3 position slide switch brazil		Send Order
	SK-22F03	50V	0.3A	Slide Switch DPDT 115V To 230V Voltage selector 2 position 6pins Terminal Straight PCB Voltage slide switches		Send Order
	SK-12D01	50V	0.3A	MINI slide switch 1P3T Handle high 2.5mm SMT SMD 8 pin micro slide switches with fixed pin		Send Order
	SK-12D02	50V	0.3A	8 Pin 2 Position Mini Size Slide Switches for Security Products		Send Order

• Slide Switches

  FBelec sliding switch has good quality and low price, and focusing on switching for 20 years
  with independent R & D and design and full automation of the production line.



•
• 1p4t toggle switch sk-14d02 low current four gear paragraph type hand feeling white handle toy switch

• Benefits of Slide Switches

  Slide switches offer several benefits in various applications due to their simple design, ease of use and low cost.  Their versatility makes them a popular choice in many industries.

  1. Simple Operation: Slide switches have a straightforward on/off operation. Users can easily slide the switch to the desired position to turn a device or function on or off, making them intuitive and user-friendly.

  2. Durable and Reliable: Slide switches are typically designed to withstand mechanical stress and wear, making them reliable for long-term use. They can endure repeated sliding without significant degradation in performance.

  3. Compact Design: Slide switches have a compact form factor, which makes them suitable for applications with limited space. Their small size allows for easy integration into various electronic devices and equipment.

  4. Low Cost: Slide switches are often relatively inexpensive to manufacture, making them a cost-effective choice for basic on/off control functions.

  5. Visual Indicator: Some slide switches include a visual indicator, such as a colored stripe or a light, to indicate the switch's position (on or off). This feature can provide users with immediate feedback about the status of the device.

  6. No Power Consumption: Slide switches do not consume any power themselves; they simply establish or break a physical connection. This can be advantageous in applications where minimizing power consumption is critical.

  7. Manual Override: Slide switches can offer a manual override option, allowing users to directly control a function or device even if automated systems are in place. This can be useful in situations where immediate control is necessary.

  8. Resistance to Accidental Activation: Slide switches are less prone to accidental activation compared to push-button switches, as they require deliberate sliding action to change their position.

  9. Customizable Options: Slide switches come in various configurations, including single-pole single-throw (SPST), single-pole double-throw (SPDT), double-pole single-throw (DPST), and more. This variety of options allows designers to choose the right switch for their specific application.

  10. Versatility: Slide switches can be used in a wide range of applications, from consumer electronics (e.g., smartphones, remote controls) to industrial equipment (e.g., machinery control panels). Their versatility makes them a popular choice in many industries.

  CW offers the most comprehensive line of slide switches for panel or PC board mounting.

•





  The principle of sliding switches

  A sliding switch is an electronic component composed of a switch and a guide rail. The switch section is usually composed of two or more contacts, while the guide rail section is composed of guide rails with protrusions and grooves alternating. When the slider slides, the protrusions and grooves on the guide rail will cause the contacts to connect or disconnect the circuit, achieving on/off control of the circuit.

  Application of sliding switches

  Sliding switches are widely used in electrical control systems, audio equipment, electronic instruments, and other fields. For example, sliding switches can be used in audio equipment to control the volume level, or sliding switches can be used in electrical equipment to control the on/off of circuits.



  How to choose a sliding switch

  When choosing a sliding switch, the following points should be noted:
  1. Number of contacts: Choose the appropriate number of contacts according to your own needs;
  2. Load current and voltage: Choose a suitable range of load current and voltage for your own circuit;
  3. Conductive materials: Select suitable conductive materials according to the usage environment, common ones include copper alloy, copper nickel alloy, etc;
  4. Lifetime: Choose sliding switches with different lifetimes according to your own needs.
  In summary, sliding switches are a very common electronic component with a wide range of applications, but when purchasing, attention should be paid to factors such as the number of contacts, load current and voltage, conductive materials, and lifespan. I hope this article provides beginners with a certain understanding and understanding of sliding switches.



  Advantages and disadvantages of

  sliding switches

  1. Advantages: Sliding switches have the advantages of simple structure, high reliability, and long service life, and are widely used in many electronic products. Compared to other types of switches, sliding switches are more flexible and convenient, and have a good feel during operation.
  2. Disadvantages: Sliding switches also have some drawbacks, such as poor contact and susceptibility to contamination. Firstly, as sliding switches achieve circuit interruption and connection through contact or separation of contacts, poor contact can affect the normal operation of the circuit. Secondly, as the sliding switch is a mechanical switch, it is inevitably affected by external oil stains, dust, and other factors, which can affect its service life.
  Sliding switches, as a common electronic component, have a wide range of applications in various fields. Of course, in practical use, we need to pay attention to avoiding prolonged use and inappropriate reciprocating use, in order to avoid sliding contact wear and affecting switch performance.

• Sliding switch is a switch used to operate on and off laterally, so it is defined as sliding switch. It is also one of the switches with the most varieties.





  What is the main function of the slide switch?

  By pushing the button handle equipped with moving contact to slide, the moving contact piece is connected from one group of static contact pieces to another group of static contact pieces to realize the switch of circuit replacement.

  Slide switch including PCB pin type and SMT Slide Switch, mini slide switch, standard size slide switches, SPDT switches.

• The factory produces more than 700,000 switches per day Only

  the switch is widely used in various electrical appliances, medical and health care equipment,
  electronic toys, lighting, audio, radio and digital electronic products, etc.,
  and has won the trust and praise of new and old customers with good results!
