SMD Buzzer

Picture	Manufacturer No.	Size	Rated Voltag (V)	Operating Voltage (V)	Current Consumption (mA)	SPL (dB)	Resonant Frequency (Hz)	Description	Datasheet	Order
	SMT1030R	10*10*3	3	2～5	≤40	≥85@10cm	4000±500	10mm mini SMD buzzer		Send Order
	SMT1109S	11*9*1.7	5	1～25	≤3	≥75@10cm	4000±500	11mm SMD intervox buzzer		Send Order
	SMT1117	11*9*1.7	5	1～25	≤3	≥75@10cm	4000±500	11mm Piezoelectric SMD buzzer		Send Order
	SMT1210	12.8*12.8*10	5	4～8	≤40	≥85@10cm	2400±500	12x12x10mm square SMT buzzer		Send Order
	SMT1225	12*12*2.5	5	1～25	≤3	≥80@10cm	4000±500	12mm SMD electromechanical buzzer		Send Order
	SMT1230	12*12*3	3	2～5	≤40	≥85@10cm	4000±500	12x12x3mm 3v electronic mini buzzer		Send Order
	SMT1325	13*13*2.5	5	1～25	≤3	≥75@10cm	4000±500	13mm electronic small piezo alert buzzer		Send Order
	SMT1445	14*14*4.5	5	1～25	≤2	≥75@10cm	4000±500	14mm aktiver SMD buzzer		Send Order
	SMT1625	16*16*2.5	3	1～25	≤2	≥75@10cm	4000±500	16mm SMT Miniature buzzer		Send Order
	SMT1706	17*17*6	12	1～25	≤5	≥90@10cm	2500±500	17mm SMD transducer indicator sounder		Send Order
	SMT1750A	17*17*5.0	5	1～25	≤2	≥80@10cm	4000±500	17mm small size Miniature buzzer		Send Order
	SMT1818	18*18*8	5	1～25	≤2	≥80@10cm	4000±500	18mm smd piezo transducer		Send Order
	SMT4020	4*4*2	3	1～25	≤2	≥70@10cm	4000±500	mini size 4*2mm smd buzzer		Send Order
	SMT5020	5*5*2	3	1～25	≤2	≥70@10cm	4000±500	5*2mm electronic SMD small buzzer		Send Order
	SMT5030	5*5*3	3	1～25	≤2	≥70@10cm	4000±500	5*5*3 smd piezo buzzer		Send Order
	SMT5517	5*5*1.7	3	1～25	≤2	≥70@10cm	4000±500	5*5*1.7 SMT buzzer with matel		Send Order
	SMT7525	7.5*7.5*2.5	3	1～25	≤2	≥70@10cm	4000±500	7.5x7.5x2.5 smd surface mount buzzer		Send Order
	SMT8503	8.5*8.5*3	3.6	1～25	≤90	≥85@10cm	3000±500	8.5x8.5x3mm SMT piezo alert buzzer		Send Order
	SMT8504	8.5*8.5*4	3.6	1～25	≤90	≥85@10cm	2730±500	8.5x8.5x4mm intervox SMD buzzer		Send Order
	SMT9020	9*9*1.8	3	1～25	≤80	≥85@10cm	4000±500	9*9*1.8mm piezo SMD buzzer		Send Order
	SMT9032	9*3.2	3	1～25	≤80	≥85@10cm	2731±500	9.0*3.2mm SMD arduino sounder		Send Order
	SMT9040	9*4	3	1～25	≤80	≥85@10cm	2731±500	9*4mm SMD electronic mini buzzer		Send Order
	SMT9045	9*4.5	3	1～25	≤80	≥85@10cm	2731±500	9x4.5mm mini SMD transducer		Send Order
	SMT9650	9.6*9.6*5	3	1～25	≤30	≥85@10cm	2700±500	9.6mm SMD Transducer Indicator Sounder		Send Order
