SMD LED

Picture	Manufacturer No.	Size	Forward Voltage	Reverse Voltage	Color Rendering Index	Description	Datasheet	Order
	FBSMDL-0402-O	0402	2.0-2.2（V）	5（V）	80	Factory direct sale super bright 0402LED lamp beads micro patch type 1005 orange light emitting diode		Send Order
	FBSMDL-0402-P	0402	3.0-3.2（V）	5（V）	80	Factory Outlet 0402 Pink Bead Sticker LED Lamp 0402 Pink Light Emitting Diode Highlight LED Lamp Bead		Send Order
	FBSMDL-0602-P	0602	2.0-2.2（V）	5（V）	80	Factory wholesale patch 0602 side light emitting diode purple lamp 1606 purple LED patch uv lamp beads		Send Order
	FBSMDL-0603	1615	2.8-3.0（V）	10（V）	90	Three-color lamp beads 1615 white, green and orange 0603 orange, white and green with a total of yang and a total of negative LED patch green, white, orange, orange, green and white		Send Order
	FBSMDL-0602-W	0602	3.0-3.4（V）	5（V）	80	Factory direct SMD 1606led white light 0602 white light 0603 side light emitting diode highlight indicator		Send Order
	FBSMDL-0603-P	0603	2.0-2.2（V）	5（V）	80	smd 0603 purple highlight led lamp beads 0603 purple light SMD light-emitting diode 1608 violet		Send Order
	FBSMDL-0805-P	0805	2.8-3.2（V）	3（V）	80	Manufacturer 0805 pink patch led lamp beads light-emitting diode 0805 pink light pink light bright pink		Send Order
	FBSMDL-1204-O	1204	1.8-2.2（V）	5（V）	80	Factory direct sales side led patch light source 3210 orange light side stick lamp beads 1204 side light emitting diode		Send Order
	FBSMDL-2835-R	2835	3.0（V）	5（V）	70	Factory direct 2835 red light 0.1W SMD LED lamp beads bright red light red light-emitting diode		Send Order
	FBSMDL-5050	5050	2.0-3.4（V）	5（V）	80	Manufacturer 5050 Symphony built-in ic Symphony LED marquee 5050rgb light strip SK6812 point control breakpoint resume		Send Order

•
  Why Choose Us

• •

    Strong R&D Forces

  •

    Diverse Product & Customized Serivce

  •

    Reliability Assurance & Quality Commitment

  •

    Outstanding Service Level

•

•

  What is SMD LED?

  The SMD (surface mounted device) LED is a small electroluminescent diode created by deposition. Miniaturization saves significant space and allows grouping several LEDs in the same housing. It is a simple lamp that emits light by passing current through a compound semiconductor and combining electrons and holes. The excess energy is released in the form of light, achieving the effect of emitting light.

  SMT LED is attached to the surface of circuit boards, suitable for SMT processing, and can be reflow soldered. SMT LED solves problems such as brightness, viewing angle, flatness, reliability, and consistency very well. Compared with other packaging devices, it has advantages such as strong vibration resistance, low solder joint defect rate, and good high-frequency characteristics.


  It packages more LED chips on a smaller area, uses lighter PCB and reflective layer materials, and requires less epoxy resin to fill the reflective layer. By removing heavier carbon steel material pins and reducing size, the weight of the product can be easily reduced by half. The volume and weight are only about 1/10 of traditional plug-in components. After using SMT packaging, the volume of electronic products is reduced by 40% to 60%. The weight has been reduced by 60% to 80%, ultimately making the application more perfect.
  The packaging of straight in LED adopts the form of encapsulation. The sealing process involves first injecting liquid epoxy resin into the LED molding cavity, then inserting the pre welded LED bracket, placing it in an oven to allow the epoxy resin to cure, and then detaching the LED from the mold cavity to form. Due to its relatively simple manufacturing process and low cost, it has a high market share.

• Applications

•
•

• Advantages

  Powerful and durable / Low power consumption

  Less heat-sensitive / Light quality



  Disadvantages

  Price

  Increased heat production



•


  SMD stands for Surface Mounted Devices, a special type of high power LED lights. With no wires, these devices provide less fuss and with seamless application. Instead, SMDs have tiny metallic contacts that can be directly soldered to circuit boards. FBelec's vast selection of SMD LEDs are sure to fit your needs. Our surface mount device LEDs are energy efficient and provide a superior lighting experience.


  Contact FBelec today for more information about the products below.




•
• China Leading SMD LED Manufacturer

•


  Top-Emitting Chip SMD LED

  Our top-emitting chip SMD LEDs can provide the lighting you need for portable consumer electronics, backlighting, and indicator applications. All of our top emitting LEDs provide high intensity output.




  High Temperature SMD LED

  Our high temperature SMD LED features in the most desirable top emitting and right angle packages. Available in both single and bi-color options. Providing a broard selection of LEDs that can withstand harsh environment and high operating temperature up to 100°C.




  Top-Emitting PLCC SMD LED

  The PLCC SMD LED product line provides high intensity, top-emitting lighting true to its name. These products provide strong reliability and competitive lead times, making them a best seller. You'll find these LEDs in a range of color combinations, sizes, shapes, and viewing angles.







  Low Current SMD LED

  Our low current SMD LED is engineered to meet the low current and low forward voltage (VF) requirements typically associated with battery operated devices and mobile electronics, while still maintaining a high luminosity output. Available in various top emitting, right angle in single, bi-color and tri-color selections.




  Main Models

  SMD LED 3528

  3528 SMT beads, power 0.06w, lumen values 6-7LM, 7-8LM, 8-9LM, with a maximum light efficiency of 150LM/w.

  SMD LED 2835

  2835 SMT beads, power 0.2w, lumen values 20-22LM, 22-24LM, 24-26LM, with a maximum light efficiency of 130LM/w.

  SMD LED 5050

  5050 SMT beads, power 0.2w, lumen values 20-22LM, 22-24LM, 24-26LM, with a maximum light efficiency of 130LM/w.

  SMD LED 5630

  5630 SMT beads, power 0.5w, lumen values 50-55LM, 55-60LM, with a maximum light efficiency of 130LM/w.

  SMD LED 3014

  3014 SMT beads, power 0.1w, lumen values 11-12LM, 12-13LM, with a maximum light efficiency of 130LM/w.




• A light emitting diode (LED) is a semiconductor device which can create a light source of various colors utilizing a compound semiconductor material such as GaAs, AlGaAs, GaN, InGaN, and AlGaInP. Generally speaking, the LED chips need to be packaged to offer mechanical support, electrical connection, optical guidance, and heat flux path to outside. Following that, the LED packages are integrated into systems as a function unit. An SMD (surface mounted devices) LED is an LED package manufactured by soldering light-emitting diode package structures onto a circuit board utilizing a surface mount technique. The SMD housings are typically fabricated from plastic and can be termed asplone of which is a Plastic Leaded Chip Carrier (PLCC) in which the square-shaped 32-pin package is provided with leads extracting in a T-shaped way from four sides of the package and has a figure dimensioned more compact compared to a DIP package, and the other of which is a Ceramic Leaded Chip Carrier (CLCC) with leads extracting in a T-shaped way from four sides of the package. The SMD LEDs package has advantages in compact design, low cost, high lumen output, low lumen depreciation, efficient heat dissipation, and more flexible in system integration. These LEDs have high reliability performance and are made to work under a broad range of environmental conditions. This high reliability feature makes them ideally fitted to be used under illumination application conditions. SMD LEDs are named by their sizes. SMD 2835, for example, the most well known SMD configuration on the market and offers the best cost / performance among the SMD packages, are called this way because the dimensions of the chips are 2.8mm x 3.5mm. Other SMD chips available on the market including 3014, 3528, 4014, 5050, 5630, 5730, etc. Typical lighting products for LED chips packaged within SMD housings include for example, but are not limited to, LED light bulbs, LED tubes, LED panels, LED linear light fixtures, LED strips, LED downlights, LED flood lights, LED high bay lights. Top SMD LED manufacturers includes FBelec, Cree, Bridgelux, Philips LumiLEDs, Osram, Epistar, Samsung, Seoul Semiconductor, LG, Honglitronic, Sanan, MLS, ETi, Everlight, Nichia, Sharp, etc.astic leaded chip carriers (PLCCs). SMD housings generally feature an LED chip connected to multiple metal leads formed from a leadframe and can optionally include a heat slug. The power is supplied to the circuit board and is delivered correspondingly to p-type electrodes and n-type electrodes of light-emitting diode chips through lead frames of the light-emitting diode package structure to have the light-emitting diode chips produce light. The surface mount package is generally categorized into two types.
